Features
- Supports 1.25 Gb/s bit rates
- Duplex LC connector
- Hot pluggable SFP footprint
- Cooled DML transmitter and PIN receiver
- Applicable for 80km SMF connection
- Low power consumption, < 1.5W
- 100 GHz channel spacing
- Digital Diagnostic Monitor Interface
- 24dB power budget
- Operation temperature range: -5 to 70 °C
Description
WaveSplitter’s WST-SFP-DZRxx-x Enhanced Small Form Factor Pluggable SFP+ transceivers are designed for use in 1.25 Gigabit Ethernet links up to 80km over SingleMode fiber. They are compliant with SFF- 8431,SFF-8432 and ITU-T G.698.1. The transceiver designs are optimized for high performance and cost effective to supply customers the best solutions for telecommunication.
This transceiver consists of two sections: The transmitter section incorporates a cooled DML laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
Specification
